Canon imagePROGRAF TM-240 Online Manual

Setting Paper Dimensions (Custom Size)
You can specify the height and width of paper when its size cannot be selected from the Page Size. Such a
paper size is called "custom size."
There are two ways of setting a user-defined paper, setting the paper from Size Options... on the Page
Setup tab and setting the paper from Custom Size of Page Size.
If you will be using a user-defined paper repeatedly, setting it from Size Options... is convenient because it
becomes registered to Page Size and can be selected any time after that.
If you want to use a user-defined paper temporarily, setting it from Custom Size is suitable.
The procedure for specifying a custom size is as follows:
Setting from Paper Size Options
1.
Open the printer driver setup window
1.
2.
Click Size Options... on the Page Setup tab
2.
The Paper Size Options dialog box opens.
3.
Set user-defined paper
3.
Set Custom Paper Size Name, Units, and Size, and then click Add.
For Size, specify a size or select the paper size to be used from Paper Size List.
To narrow down the paper sizes displayed in Paper Size List, select the Display Series check box.
134

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
