Canon imagePROGRAF TM-240 Online Manual

Paper is not cut straight
Check 1
Is the edge of the paper cutting position creased?
Straighten out any curling by the edges of the paper.
Check 2
Is the edge of the paper cutting position lifting up when cutting?
Reload the paper correctly.
Check 3
Is the paper a type that can be cut with the cutter blade?
Set Cutting mode in the touch screen menu to User cut, then and cut the roll paper with a cutting implement
such as scissors.
Specifying the Cutting Method for Rolls
Cutting Roll Paper after Printing
Check 4
Are you using the basket properly?
Make sure that you are using the basket properly.
Using the Basket on the Printer Stand
Check 5
Check that the Cut speed setting is correct.
If the paper edge cannot be cut straight at the cut starting position, it may be improved by selecting slower cut
speed than that selected currently.
If the paper edge cannot be cut straight at the cut ending position, it may be improved by selecting faster cut
speed than that selected currently.
Select paper settings display area on Home screen of touch screen, then select Paper settings > Advanced
and change the setting value of Cut speed.
Advanced (Paper settings)
Check 6
Did the printing material slip diagonally while being cut?
Set the Cutting mode in the touch screen menu to Eject cut, and then hold and cut the material after it has
printed.
Specifying the Cutting Method for Rolls
Cutting Roll Paper after Printing
Check 7
Is the cutter blade attached properly?
Attach the cutter blade properly.
Replacing the Cutter Blade
731

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
