Canon imagePROGRAF TM-240 Online Manual

Countermeasures against Unauthorized Access
This section describes countermeasures against an unauthorized access to the printer from outside. When
you use the printer via a network or you are an administrator, we recommend you read this section before
using the printer.
Four countermeasures below can be helpful against an unauthorized access.
Specify a Private IP Address
Restrict Communication Using Firewall or Wi-Fi Router
Specify a Password for the Printer
Apply higher security level for Wi-Fi connection
Note
• As the setting procedure described below is an example, it may be different from that of your printer.
For details, refer to your printer's manual.
Specify a Private IP Address
An IP address is a numeric label assigned to each device on the network. There are two types of IP
address. One is used for internet connection ("global IP address"), and the other is used for a local area
network such as an inhouse LAN ("private IP address").
If a global IP address is specified for the printer, many and unspecified users on internet can access to
the printer. As a result, you will face an increased risk of information leakage caused by an unauthorized
access from outside. On the other hand, if a private IP address is specified for the printer, users who can
access to the printer are confined to those on a local area network such as an inhouse LAN. Therefore,
we recommend you specify a private IP address for the printer.
The range of addresses used as a private IP address is shown below. Make sure whether a private IP
address is specified for your printer.
Range of private IP address
• 10.0.0.0 to 10.255.255.255
• 172.16.0.0 to 172.31.255.255
• 192.168.0.0 to 192.168.255.255
Procedure to check the IP address
Select Setup > Device settings > LAN settings on your printer to select a network connection method
and check the IP address. For the procedure to check and specify the IP address, refer to your printer's
manual.
Note
•
Establishing an environment to protect an access from outside using a firewall can reduce a risk of an
unauthorized access even though a global IP address is specified for your printer.
509

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
