Canon imagePROGRAF TM-240 Online Manual

Example Basket Configurations
When printing line drawings on plain paper, you can use the basket not only at the regular position but also
at two kinds of extended positions convenient for catching printed material.
In these extended positions, the basket can collected up to approximately 20 sheets of printed material.
The paper sizes that can be used with these extended positions are shown in the table below. Use the best
position that suits the paper size and orientation.
Important
• Use the regular position in the following situations. If you print multiple sheets in the regular position,•
remove the printed material from the basket one sheet at a time.
Paper other than plain paper
Paper sizes not listed in the following table and printed material other than line drawings
If the paper curls excessively due to the qualities of the paper or the usage environment
If the paper curls excessively near the end of a roll of paper
• Return the basket to the regular position after printing.•
Extended position A
Paper orientation SD-35 / SD-34 SD-26 / SD-25
Portrait 36"x48" (ARCH E) (914.4 x 1219.2 mm)
24"x36" (ARCH D) (609.6 x 914.4 mm)
A0 (841.0 x 1189.0 mm)
A1 (594.0 x 841.0 mm)
24"x36" (ARCH D) (609.6 x 914.4 mm)
A1 (594.0 x 841.0 mm)
Extended position B (SD-35 / SD-26 only)
Paper orientation SD-35 SD-26
Landscape 24"x36" (ARCH D) (609.6 x 914.4 mm)
18"x24" (ARCH C) (457.2 x 609.6 mm)
A1 (594.0 x 841.0 mm)
A2 (420.0 x 594.0 mm)
18"x24" (ARCH C) (457.2 x 609.6 mm)
A2 (420.0 x 594.0 mm)
Regular position
75

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
