Canon imagePROGRAF TM-240 Online Manual

Cut to standard size
Specifies standard size as the output page size when printing on roll paper.
Display this item by selecting the following.
(Setup) > Printer settings > Print settings > HP-GL/2 print settings > Paper settings
• ON•
Cuts to standard size in accordance with the roll paper width.
When there are two lengths/widths applicable for a given roll paper width, the optimum size is selected
automatically.
Note
• Nesting cannot be performed while ON is selected. (TM-355/TM-255/TM-5355/TM-5255)
• If ON is selected for Save paper and there is blank space above/below the image, the size will not
be standard size.
• When ON is selected for Print centered, printing will be in the center of the standard size.
• If there is no standard size corresponding to the roll paper width, operation is the same as if OFF is
selected. No message is displayed.
• For information about supported standard sizes, see Standard Size Table.
• OFF•
Cutting according to standard size is not performed.
STANDARD CUT EXAMPLES
• A3-size width roll paper•
A. Position of cut when OFF
B. Position of cut when ON
• A3-size width roll paper•
400

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
