Canon imagePROGRAF TM-240 Online Manual

Set a PIN Code for Print Jobs
If you set a PIN code to your print jobs, the print jobs remain in standby status until the PIN code is entered
on the printer operation panel.
As the material is printed immediately after entering the PIN code, issues such as retrieving the wrong
documents and allowing others to peek at your documents can be prevented.
The procedure for setting a PIN code to your print jobs is explained here.
1.
Open the printer driver setup window
1.
2.
Set the output method
2.
Click Output Method... in the Page Setup tab.
3.
Set the PIN code
3.
Place a checkmark next to Set PIN for printing, and enter a one to seven-digit number in PIN.
4.
Complete the setup
4.
Click OK.
When you print, the print job is set to standby status on the printer unit.
If you enter the PIN code you set on the printer operation panel, the print job will be printed.
Note
• See "Printing Security Print Jobs" for instructions on how to operate using the printer operation panel.
• Print jobs with a PIN code set are not saved on the printer hard disk.
• Depending on the model you are using, this feature may be unavailable.
210

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
