Canon imagePROGRAF TM-240 Online Manual

Selecting Enable HTTPS redirection redirects the communication using CHMP to encrypted
communication.
Note
• To use CHMP for encrypted communication, you need to register the printer's root certificate to
your computer.
Registering Printer's Root Certificate to Local Computer for SSL Communication
• CHMP is a Canon proprietary protocol.
◦ Network interface settings◦
To connect to a hub that supports spanning tree, select Spanning tree settings > Enable.
Selecting Enable avoids circulating data on a network.
◦ DRX settings◦
When enabled, data is received intermittently during network connection.
◦ IP filtering◦
Allows or denies access for specific IP addresses.
Settings for both IPv4 and IPv6 addresses can be specified.
Important
• If the device address for the administrator has been set to rejection by mistake, select •
(Network) on the HOME screen of the operation panel, and then select LAN settings > Wi-Fi /
Wireless Direct / Wired LAN > Settings > Advanced > Reset LAN settings in this order, and
initialize network information of the printer.
After resetting, perform setup again as necessary.
◦ MAC address filtering settings◦
Allows or denies access for specific MAC addresses.
Important
• If the device address for the administrator has been set to rejection by mistake, select •
(Network) on the HOME screen of the operation panel, and then select LAN settings > Wi-Fi /
Wireless Direct / Wired LAN > Settings > Advanced > Reset LAN settings in this order, and
initialize network information of the printer.
After resetting, perform setup again as necessary.
◦ Reset LAN settings◦
Initializes the network settings on the printer.
After resetting, perform setup again as necessary.
457

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
