Canon imagePROGRAF TM-240 Online Manual

• The inside surface of the protective cap is coated with ink to protect the nozzle. Be careful not
to touch these surfaces when removing the caps.
•
The print head contains ink to protect the nozzle. We recommend removing the protective cap
while holding it over the pouch that contained the print head or otherwise safely out of the way
to avoid spilling ink and staining your clothes or the surrounding area. If ink accidentally spills,
wipe off the ink with a dry cloth.
•
If you need to put a print head somewhere temporarily before installation, do not set it down
with the nozzles and metal contacts facing down. If the nozzles or metal contacts are damaged,
it may affect the printing quality.
•
Do not reattach the removed protective part. Dispose of these materials in accordance with
local regulations.
13. Turn ink holes (K) toward the front and insert print head into carriage.13.
Insert the print head all the way into the carriage, while taking care to keep parts that were protected
by the protective caps from touching the carriage.
14.
Grasp tab (D) of print head locking cover and lower it to front to lock print head.
14.
595

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
