Canon imagePROGRAF TM-240 Online Manual

Printer and Stand SD-34 (when opening the basket and standing up the
operation panel):
Approx. 50.6 x 34.2 x 41.9 in. (1285 x 868 x 1064 mm)
* For Extended position, see Example Basket Configurations.
Weight Printer only (without print head and ink tanks):
Approx. 111 lb (50 kg)
Printer and Stand SD-35 (without print head and ink tanks):
Approx. 142 lb (65 kg)
Printer and Stand SD-34 (without print head and ink tanks):
Approx. 139 lb (63 kg)
Space for installation (W x D x
H)
Printer and Stand SD-35
Approx. 66.4 x 66.9 x 65.6 in. (1685 x 1698 x 1664 mm)
Printer and Stand SD-34
Approx. 66.4 x 57.8 x 65.6 in. (1685 x 1468 x 1664 mm)
TM-255 / TM-5255
Power supply 100-240 V AC (50/60 Hz)
Power consumption When printing (wired LAN connection): Approx. 64 W
Standby (wired LAN connection): Approx. 1.6 W
Standby (all ports connected): Approx. 2.2 W
When power is off: Approx. 0.1 W *1
*1 The printer uses a trace amount of power even when turned off. To stop all
power consumption, turn off the printer and unplug the power cord.
Operating environment Temperature: 59 to 86 °F (15 to 30 °C)
Humidity: 10 to 80 % RH (with no condensation)
Dimensions (W x D x H) Printer only (when standing up the operation panel):
Approx. 38.6 x 29.5 x 17.5 in. (978 x 748 x 443 mm)
Printer and Stand SD-26 (when opening the basket and standing up the
operation panel):
Approx. 38.6 x 34.9 x 41.9 in. (978 x 885 x 1064 mm)
Printer and Stand SD-26 (when setting the position to extended position
B and standing up the operation panel) *:
Approx. 38.6 x 43.3 x 41.9 in. (978 x 1098 x 1064 mm)
Printer and Stand SD-25 (when opening the basket and standing up the
operation panel):
Approx. 38.6 x 34.2 x 41.9 in. (978 x 868 x 1064 mm)
* For Extended position, see Example Basket Configurations.
928

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
