Chapter 5
5-45
5.6.6.3 Print Test
5.6.6.3.1 PRINT Test
0006-5856
The Print Test menu is selected by pressing the numeric button 3 from the test mode menu.
In this test, various print patterns are output from the printer. As service print patterns, press the numeric button 2
from the Print Test menu to select "3-2: BLACK" or press the numeric button 6 to select "3-6: ENDURANCE". Do
not use the other patterns. They are for development and factory use.
Check for white stripes and unevenness on the Black pattern, and check for image shrinkig, stretching, soiling, and
black strips on the Endurance pattern.
F-5-12
Memo
After completion of the print test, if the printing was normal, copy a document. If there is any defect in the
copied image, there is a defect in the scan section.
