Canon LaserBase MF5600 - Operation Panel

Chapter 1
1-12
1.3.2 Operation panel
0005-8054
F-1-7
T-1-13
[1] One-touch dial keys [13] Energy Saver key
[2] Coded Dial key [14] Directory key
[3] Redial/Pause key [15] Hook key
[4] In Use/Memory indicator [16] Status Monitor key
[5] Alarm indicator [17] Clear key
[6] COPY key [18] LCD
[7] FAX key [19] Start key
[8] SCAN key [20] Stop/Reset key
[9] Menu key [21] OK key
[10] Cursor key [22] Collate/2on1 key
[11] Enlarge/Reduce key [23] Image Quality key
[12] Exposure key [24] Numeric keys
01 02 03
04
05
06
07
08
09
10
1
23
4
5
6
7
8
9
0
11 12
[1] [2] [3] [4][5][6] [7] [8] [9][10][11][12] [13]
[15][14] [17][16] [18] [19] [20] [21] [22] [23] [24]
