SADRŽAJ
HR-2
HR
1. PRIPREMA ZA UGRADNJU ................................................................................................... 3
2. PREGLED UGRADNJE .......................................................................................................... 7
3. DIJAGRAM UGRADNJE ........................................................................................................ 8
4. SPECIFIKACIJE ..................................................................................................................... 9
5. UGRADNJA VANJSKE JEDINICE ....................................................................................... 10
5.1 Upute za ugradnju vanjske jedinice ....................................................................................................... 10
5.2 Ugradnja drenažnog zgloba .................................................................................................................... 12
5.3 Napomene o bušenju rupe u zidu .......................................................................................................... 12
5.4 Odabir unutarnje jedinice od 24000 Btu/h ............................................................................................. 12
6. SPAJANJE CIJEVI RASHLADNOG SREDSTVA ................................................................ 13
7. OŽIČENJE ............................................................................................................................. 15
7.1 Sigurnosne mjere ..................................................................................................................................... 15
7.2 Ožičenje vanjske jedinice ........................................................................................................................ 15
7.3 Dijagram ožičenja .................................................................................................................................... 17
8. ISPUST ZRAKA .................................................................................................................... 20
8.2 Upute za ispust ........................................................................................................................................ 20
8.4 Napomena o dodavanju rashladnog sredstva ...................................................................................... 21
9. POKUSNI RAD ..................................................................................................................... 22
10. FUNKCIJA AUTOMATSKOG ISPRAVLJANJA OŽIČENJA/CIJEVI .................................. 23
11. INFORMACIJE O SERVISIRANJU ..................................................................................... 24
Tip Naziv modela Dimenzija (ODU) Nazivni napon i Hz
Vanjska jedinica
38QUS014DS2*
38QUS018DS2-2/38QUS018D8S2
800x333x554
220-240V~ 50 Hz
38QUS018DS2*
38QUS021DS3*
38QUS027DS3*/38QUS027D8S3*
845x363x702
38QUS028DS4*
38QUS036DS4*/38QUS036D8S4*
38QUS042DS5*/38QUS042D8S5*
946x410x810
Unutarnja jedinica
postavljena na zid
42QHC007DS*/42QHC007D8S*
42QHC009DS*/42QHC009D8S*
730×192×291
42QHC012DS*/42QHC012D8S* 812×192×300
42QHC018DS*/42QHC018D8S* 973×218×319
42QHC024DS*/42QHC024D8S* 1082×225×338
S cijevima
Unutarnja jedinica
42QSS009DS*
42QSS012DS*
700x635x210
42QSS007D8S*
42QSS009D8S*
42QSS012D8S*
700×450×200
42QSS018DS*/42QSS018D8S* 880x674x210
42QSS024DS*//42QSS024D8S* 1100x774x249
Spremnik
Unutarnja jedinica
42QTD007DS*
42QTD009DS*/42QTD009D8S*
42QTD012DS*/42QTD012D8S*
42QTD018DS*/42QTD018D8S*
570x570x260
42QTD024DS* 840x840x245
Konzola
Unutarnja jedinica
42QZA009DS*
700x600x21042QZA012DS*/42QZA012D8S*
42QZA018DS*
