Troubleshooting
TruVu™ VAVB3-E2 CARRIER CORPORATION ©2022
Installation and Start-up Guide All rights reserved
101
To configure custom Prog 1/2 LEDs
You can customize the Prog 1 and/or Prog 2 LED for site-specific purposes by configuring the BACnet Analog
Output (BAO) microblock.
Open your control program in the Snap interface, select the AO microblock for each LED, and use the following
settings:
Expander number :
Channel number
• <=0 Normal
• >15 On
The number of blinks equals the
Present Value.
The pulse pattern repeats after a
2-second delay
LED will blink the number of
times given in the BAO with ON
pulse 0.5 seconds and OFF pulse
0.5 seconds.
• <=0 Normal
• >15 On
The number of blinks equals the
Present Value.
The pulse pattern repeats after a
2-second delay
LED will blink the number of
times given in the BAO with ON
pulse 0.5 seconds and OFF pulse
0.5 seconds.
To get a Module Status report
A Module Status report provides information about the controller and verifies proper network communication with
the controller. You can get this report:
• In the i-Vu® application—Right-click the controller on the navigation tree, then select Module Status.
• In the Field Assistant application—Right-click the controller in the navigation tree and select Module Status.
• On the controller setup ModStat tab—See To set up the controller through the Service Port (page 88).
See Module Status field descriptions (page 145) in the Appendix.
