Carrier TruVu VAVB3-E2 - Appendix C: ZS Sensor Display for TV-VAVB3-E2

Appendix C: ZS Sensor display for TV-VAVB3-E2
TruVu™ VAVB3-E2 CARRIER CORPORATION ©2022
Installation and Start-up Guide All rights reserved
141
Property
ZS Screen
Rnet Tag
Rnet Text
1
Description
Active Alarms
Diagnostic
1550
-nonE
StP-AL
SPco2-AL
SP_rH-AL
Sat-AL
No Active Alarms
Zone Temp Alarm
Zone CO2 Alarm
Zone Humidity Alarm
Supply Air Temp Alarm
Active Maintenance
Diagnostic
1551
-nonE-
SnSr-FLt
Fltr-dtY
Llnc-FLt
No Active Maintenance
Sensor Fault
Dirty Filter
Linkage Fault
Active Air Source Linkage
Mode
Diagnostic
1552
OFF
hEAt-uP
hEAt
cooL
FrEEcool
PrESSrZE
EuAcuATE
vEnt
no-Llnc
Off
Warm-up
Heat
Cool
Freecool
Pressurize
Evacuate
Vent
Linkage Not Active
Supply Air Temp
Info
304
Air Source Supply Air
Temp, if available
Air Flow Percentage of
Nominal
Info
308
% of design air flow
Outdoor Air Temperature
Info
F°
Outside Air Temp
1
Rnet text is the scrolling text that appears on the ZS Pro Sensor's display.
NOTES
• To view properties on the Diagnostic Screen, hold the button for 3 seconds. Tap the button to cycle through
information to help troubleshoot your system.
• The Rnet tag is displayed on the ZS sensor display.
• To view properties on the Info Screen, press the button. Tap the button to cycle through information.
Appendix C: ZS Sensor display for TV-VAVB3-E2
