Wiring inputs and outputs
TruVu™ VAVB3-E2 CARRIER CORPORATION ©2022
Installation and Start-up Guide All rights reserved
27
To wire inputs and outputs
WARNING Do not apply line voltage (mains voltage) to the controller's ports and terminals.
The Gnd terminal is shared by the inputs/outputs to the top and bottom of it.
The TV-VAVB3-E2 has connections for one bus.
