Appendix A: TV-VAVB3-E2 Points/Properties
TruVu™ VAVB3-E2 CARRIER CORPORATION ©2022
Installation and Start-up Guide All rights reserved
136
Point Name/Description
Default/Range
Sensor Array:
Sensor calculation method - When using multiple SPT sensors, select the process
variable to be passed to the controller..
D:
R:
Avg
Avg, Min, Max
BACnet configuration:
Network Visible - Must be enabled for other BACnet objects to read or write to this
point, and for this point to generate alarms.
D:
Enabled
Object Name - Do not change.
D:
zone_temp
CO2 Sensor – The current voltage of the controller's IN-01 input.
R:
0 to 5 Vdc
Flow Control / Flow Input - The current value of the controller's flow sensor input.
R:
0 to 99999 cfm
(liters/second)
RH Sensor – The current voltage of the controller's IN-01 input.
R:
0 to 5 Vdc
T55 Zone Temp – The current value of the controller's IN-02 space temperature sensor
input.
R:
-56 to 245°F
(-48.9 to 118.3°C)
SAT Sensor – The current value of the controller's IN-03 supply air temperature sensor
input.
R:
-56 to 140°F
(-48.9 to 60°C)
Hot Wtr Vlv 1 Stat – The value provided by the controller's Smart Valve.
R:
_%
LUX – The value provided by the controller's ZS sensor to indicate lighting level.
R:
0 to 1020 lx
WS Battery Strength % — Displays charge strength indicated on the wireless space
temperature sensor. If there are multiple wireless sensors, it displays the lowest value.
R:
_%
WS Signal Strength % — Displays radio signal strength of the wireless space
temperature sensor. If there are multiple wireless sensors, it displays the lowest value.
R:
_%
Zone Humidity – The value provided by the controller's ZS or wireless sensor (if
present). See details below.
R:
_%
Zone Temp – The value provided by the controller's ZS or wireless sensor (if present).
R:
_F°
ZS Zone CO2 - IAQ/CO2 signal received from CO2-enabled ZS Sensor(s).
R:
_ppm
