SECTION 55 - ELECTRICAL SYSTEM 177
CN1
PIN FUNCTION NOTE
1 Not used
2 Key on power Wake up
3 In gear input Digital input
4 Driving lights Digital input
5 Front work lights Digital input
6 Rear work lights Digital input
7 Turn signals Digital input
8 Main beams Digital input
9 Brake fluid level low Digital input
10 Air conditioning system pressure Digital input
11 Display input switch Digital input
12 Enter input switch Digital input
13 Up input switch Digital input
14 Down input switch Digital input
15 Cranking Digital input
16 Air filter restriction Digital input
17 Not used
18 Parking brake Digital input
19 Not used
20 Idle validation switch Digital input
21 Decelerator button Digital input
22 Crab steering Digital input
23 Road steering Digital input
24 Turn steering Digital input
25 Transmission oil pressure Digital input
26 Not used
