192 SECTION 55 - ELECTRICAL SYSTEM
HYDRAULIC SPEED CONTROL (1)
It enables an increase of the moving speed of the
loader attachment.
Test procedure
(Switch Off)
Continuity should not be found between any pins.
(Switch On)
Continuity shoud be found between pins 1 and 5.
Pin No. Solenoid Resistance
1 0 V 5.0 Ω
F28464
1: C/N1
5: L-G1
F28461
1: RM:N:1
2: RM:C-L:1
