SECTION 21 - TRANSMISSION 151
ITEM DESCRIPTION QUANTITY
1 Nut - flange 1
2 Washer - flange nut 1
3O-ring - flange 1
4 Output flange front yoke 1410 with brake pads 1
5 Bearing - output shaft front 1
6 Retaining ring 1
7 Disconnect hub 1
8 Snap ring - gear retainer 1
9 Assembly - output shaft front 1
10 Bushing 2
11 Snap ring - clutch disc backing plate 1
12 Spacer 1
13 Plate - clutch disc backing 1
14 Disc - outer half 1
15 Disc - outer 11
16 Disc - inner 12
17 Disc - outer half 1
18 Retaining ring 1
19 Retainer spring 1
20 Spring - piston return 1
21 Plate spring - clutch piston wear 1
22 Assembly - clutch piston and seals 1
23 Seal - clutch piston - outer 1
24 Seal - clutch piston - inner 1
25 Assembly - output shaft rear, drum and plug 1
26 Snap ring - gear retainer 1
27 Gear lower output 1
28 Snap ring - gear retainer 1
29 Snap ring - rear bearing 1
30 Bearing - output shaft rear 1
31 Snap ring - rear bearing 1
32 Ring - piston 3
