152 SECTION 21 - TRANSMISSION
PARKING BRAKE
ITEM DESCRIPTION QUANTITY
1 Screw - brake mounting 2
2 Assembly - caliper 1
3 Nut - brake mounting screw 2
4 Nut - jam adjustment 1
5 Nut - adjustment 1
6 Washer - hardened 1
7 Washer - stainless steel 1
8 Thrust washer 1
9 Lever 1
10 Boot 1
11 Cam 1
12 Oil seal 1
13 Ball bearing 3
14 Plastic retainer 1
15 Cam 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
21
18
19
20
17
19
F27750
