238
SECTION 21 - TRANSMISSION
DISCONNECT SHAFT DISASSEMBL
Y
Use bearing puller to remo
ve the disconnect shaft
front bearing.
Remove the front bearing.
Remove the front beari
ng retaining ring.
Remove the clutch
hub from the shaft.
www
.maskinisten.net
