4 SECTION 25 - FRONT AXLES
GREASING AND LUBRICATION
DESCRIPTION POSITION
Oil level plug 1
Air breather 2
Level, fill and drain plug for reduction gear oil 3
Oil drain plug 4
Greasing points 5
