SECTION 25 - FRONT AXLES 5
Before draining the oil from axle housing, use the
breather (2) to release possible internal pressure.
SWARNING
Risk of violent oil ejection.
To drain the oil remove the level plug (1) and the
drain plug (4).
SWARNING
Risk of violent oil ejection.
Drain all oil.
Clean the drain plug (4) and tighten to the requested
torque.
Always use the oil breather (2) to release possible
internal pressure.
Unscrew the level plug (1) and fill to the bottom of
the level plug hole with the specified oil.
Wait to allow the oil to flow through the axle. Check
oil level and fill to the specified level if necessary.
Screw the level plug (1) to the prescribed torque.
Before draining the oil from the wheel hub, rotate it
so that the plug (3) is in the lowest possible position
and partially unscrew the plug to release any possi-
ble internal pressure.
Remove the plug and drain the oil.
