SECTION 25 - FRONT AXLES 7
Remove the O-ring (11) from the rear support (10).
NOTE: this is a destructive operation for the O-ring.
Remove the bolt (8) with the lube nibble (9).
Remove the bush (12) from the rear support (10).
Remove the bushes (1) from the rear support (10).
Remove the bush (13) and the thrust washer (14)
from differential support only if necessary.
NOTE: it is advisable to heat the bush (13) to make
easy this operation; this is a destructive operation
for the bush.
F27353
10
11
F27354
10
9
12
8
F27355
1
10
F27356
13
14
