SECTION 25 - FRONT AXLES 17
Assembly
Remove the swivel housing (10) from the axle shaft.
Remove the thrust washers (16) and (19) with the
bushes (17) and (18).
If it has been previously removed, reassemble the
steering stop composed by the screw (15) and nut
(14).
NOTE: do not tighten the nut (14) until the steering
angle adjustment has been done.
Insert the thrust washers (16) and (19) and the
bushes (17) and (18).
F27371
10
F27372
16
17
18
19
F37917
14 14
15
F27372
16
17
18
19
