20 SECTION 27 - REAR AXLE
IMPORTANT:
Reassembly of the bearing is the reverse proce-
dure. Using an induction heater, heat the bearing
sufficiently to expand it enough to allow it to easily
seat onto the half shaft.
After bearing removal, disassemble the seal (14)
from the shaft with wheel hub (15).
NOTE: always fit a new axle seal if the axle bearing
is removed for any reason.
