42 SECTION 27 - REAR AXLE
WHEEL HUB
Disassembly
Insert a lever between the swivel housing (14) and
the axle shaft and fit into the cardan shaft.
With the lever, push the cardan shaft in the direction
of the wheel hub to allow the removal of the snap
ring.
SWARNING
Do not damage the cardan shaft.
F27410
14
