12 SECTION 39 - CHASSIS
FRONT COUNTERWEIGHT
LOADER
BACKHOE
CAB
WHEELS
COMPONENTS TORQUES
Counterweight 700 Nm
COMPONENTS TORQUES
Loader control pipe bracket to frame 25 Nm
COMPONENTS TORQUES
Backhoe to frame hose retaining clamps 52 Nm
Boom to swing support 320 Nm
Stabilizers upper pins retaining bolt 80 Nm
Fastening pin of boom cylinder 320 Nm
Fastening pin of dipper cylinder 320 Nm
Fastening pin of bucket cylinder 320 Nm
COMPONENTS TORQUES
Cab support 450 Nm
Front cab retaining bolts 210 Nm
Rear cab retaining bolts 180 Nm
COMPONENTS TORQUES
Front/rear wheels (4WS) 700 Nm
Front wheel (2WS) 330 Nm
