SECTION 39 - CHASSIS 11
2.5 MOUNTING SCREW TORQUE
In the following table are the torques for the various assemblies that should be removed to affect repair.
IMPORTANT: always ensure prior to carrying out repairs on the machine that the vehicle parking brake is on
and the wheels are chocked.
ENGINE/TRANSMISSION
ù
FRONT AND REAR AXLE
HYDRAULIC SYSTEM
TANKS
COMPONENTS TORQUES
Engine/Transmission retaining bolts and nuts 95 Nm
Engine/Transmission bolts 95 Nm
Retaining bolts air filter-frame 25 Nm
Coolant radiator bolts to frame 95 Nm
Radiator retaining bolts to frame 95 Nm
Front cardan joint to axle 38 Nm
Front cardan joint to transmission 38 Nm
Rear cardan joint to axle 38 Nm
Rear cardan joint to transmission (Powershift) 38 Nm
Rear cardan joint to transmission (Powershuttle) 70 Nm
COMPONENTS TORQUES
Front axle retaining bolts to frame (2WS) 500 Nm
Front axle retaining bolts to frame (4WS) 500 Nm
Rear axle to frame retaining bolts (2WS) 800 Nm
Rear axle to frame retaining bolts (4WS) 900 Nm
COMPONENTS TORQUES
Power steering hoses to support frame 55 Nm
Backhoe control valve to frame bolts 90 Nm
Loader control pipes clamp to frame 25 Nm
COMPONENTS TORQUES
Oil tank bolts 85 Nm
Fuel tank bolts 85 Nm
