SECTION 55 - ELECTRICAL SYSTEM 37
COMPONENTS AND CONNECTORS
NAME DESCRIPTION
BS1 Right speaker (optional)
BS2 Left speaker (optional)
BZ1 Alarm buzzer
EV0 Fuel shut off solenoid valve
EV1 Double delivery solenoid valve (optional)
EV2 Hand hammer control valve (optional)
EV3 Rear hammer solenoid valve (optional)
EV4 Backhoe attachment travel lock solenoid
valve
EV5 Backhoe attachment lock solenoid valve
(optional)
EV6 Bucket level solenoid valve
EV8 Differential lock solenoid valve
EV11 Ride control solenoid valve (optional)
EV24 Lifting solenoid valve (optional)
EV25 Lifting solenoid valve (optional)
FG1 General fuse 80 A
FG2 A/C fuse 10A
G1 Battery
G2 Alternator
H1 Backhoe attachment lock warning light
H2 Front left light
H3 Front right light
H4 Rear left light
H5 Number plate light
H6 Rear right light
H11 Outer front left work light
H12 Outer front right work light
H13 Outer rear left work light
H14 Outer rear right work light
H15 Rotating beacon
H16 Rotating beacon
H17 Current intake illumination
H18 Cab light
H19 Inner front left work light (optional)
H20 Inner front right work light (optional)
H21 Inner rear left work light (optional)
H22 Inner rear right work light (optional)
HA1 Reverse buzzer
HA2 Horn
HA3 Optional buzzer
K01 Starting relay
K02 A/C relay
K13 Antitheft unit
K14 Transmission detachment relay
KC Fuse and relay control unit
M1 Starter motor
M4 Rear windshield wiper motor
M5 Front windshield wiper motor
M6 Rear windshield washer pump
M7 Front windshield washer pump
M9 Blower (optional)
M10 A/C compressor
R2 Engine water temperature sender
R3 Fuel level gauge
R4 Transmission oil high temperature sender
S2 4WD switch
S3 Hand hammer switch (optional)
S4 Double delivery switch (optional)
S5 Ride control switch (optional)
S7 Backhoe attachment travel lock switch
S8 Backhoe attachment lock switch (optional)
S9 Lights switch
S11 Front work light switch
S12 Rear work light switch
S15 Beacon lamp switch
S17 Start switch
S18 Parking brake switch
S20 Engine oil low pressure switch
S21 Air filter blocked switch
S24 Trasmission oil pressure switch
S26 Clutch disconnect button
S28 Bucket sensor
S29 Front horn button
S30 Rear hammer pedal (optional)
S31 Brake oil level sender
S32 Stop light switch
S33 Stop light switch
NAME DESCRIPTION
