38 SECTION 55 - ELECTRICAL SYSTEM
S34 Left cab light switch
S35 Right cab light switch
S36 A/C pressure switch
S41 Light / windshield wiper control lever
S42 Warning switch
S43 Radio (optional)
S44 Pneumo-electric seat (optional)
S45 Blower and air conditioner switch
S46 Current intake
S47 Differential lock switch
S48 EGS manual - Auto switch
S49 Battery master switch
S50 EGS
S52 Solenoid valves lock switch (optional)
S53 Rear windshield washer + wiper switch
S54 Rear horn button (optional)
S68 Cold start temperature switch
ST2 Front instrument cluster
ST3 4x1 bucket control lever
X1 General line - engine line - 18-way
connector
X2 “Grid heater” - 6-way connector
X3 Engine stop - 3-way connector
X4 Air filter - 2-way connector
X7 Reverse travel buzzer - 2-way connector
X9 General line - front instrument cluster line -
13-way connector
X10 Solenoid valve line - general line - 29-way
connector
X12 General line - upper cab line - 5-way
connector
X13 General line - front instrument cluster line -
17-way connector
X14 Anti-theft device - 11-way connector
X15 Start switch - 10-way connector
X16 Optional - 1 way connector
X17 Pneumo-electric seat - 4-way connector
X21 Left light / horn - 7-way connector
X22 Right light - 5-way connector
X23 EGS - 9-way connector
X24 Backhoe attachment travel lock solenoid
valve - 2-way connector
NAME DESC RIPTION
X25 Backhoe attachment lock solenoid valve -
2-way connector
X26 Bucket sensor - 3-way connector
X27 Pilot control audible alarm button - 2-way
connector
X28 Clutch disconnect button + differential lock
switch - 4-way connector
X29 Bucket level - 2-way connector
X30 Delivery doubling solenoid valve - 2-way
connector
X31 Quick coupler solenoid valve - 2-way
connector
X32 Rear hammer solenoid valve - 2-way
connector
X33 Differential lock solenoid valve - 2-way
connector
X34a Ride control solenoid valve - 2-way
connector
X35 Hand hammer solenoid valve - 2-way
connector
X36 Rear hammer button - 2-way connector
X37 Rear right light arrangement - 4-way
connector
X38 Rear right work light - 4-way connector
X39 Rear windshield wiper - 4-way connector
X40 Rear right work light (optional) - 4-way
connector
X41 Blower motor (optional) - 2-way connector
X42 Front direction indicator arrangement - 4-
way connector
X43 Beacon lamp - 4-way connector
X44 Front right work light - 4-way connector
X45 Front right work light (optional) - 4-way
connector
X46 Rear left work light (optional) - 4-way
connector
X47 Rear left work light - 4-way connector
X48 Rear left light arrangement - 4-way
connector
X49 Front windshield wiper - 6-way connector
X50 Front left work light (optional) - 4-way
connector
