Case 580SR+ - Page 867

SECTION 55 - ELECTRICAL SYSTEM 39
X51 Front left work light - 4-way connector
X52 Front left direction indicator arrangement -
4-way connector
X53 Radio (brown) - 8-way connector
X54 Radio (black) - 8-way connector
X55 Electrical socket - 2-way connector
X56 Front windshield wiper - 2-way connector
X57 Rear windshield wiper - 2-way connector
X61 Light / windshield wiper control lever - 12-
way connector
X63 Number plate light - 12-way connector
X64 Conditioner (optional) - 1-way connector
X67 Alternator - 3-way connector
X70 Front instrument cluster - 12-way connector
X71 Start switch - 10-way connector
X72 Pilot control - 1-way connector
X73 Engine oil low pressure switch - 1-way
connector
X80 Beacon lamp - 2-way connector
X81 Beacon lamp - 2-way connector
X82 EGS - 9-way connector
X83 EGS - 19-way connector
X84 Gearshift extension - 13-way connector
X85 Gearshift - 12-way connector
X87 General line - side instrument cluster line -
13-way connector
X88 General line - side instrument cluster line -
9-way connector
X89 Front left light - 6-way connector
X102 Control unit - 3-way connector
X103 Relay - 2-way connector
X104 Valve block switch kit - 1-way connector
X110 Air conditioner - 2-way connector
X111 Air conditioner - 9-way connector
X124 Lifting solenoid valve - 2-way connector
X125 Lifting solenoid valve - 2-way connector
XA Horn - 2-way connector
XC1 Control unit - 11-way on-board connector
XC2 Control unit - 7-way connector
XC3 Control unit - 21-way connector
NAME DESCRIPTION
XC4 Control unit - 21-way connector
XC5 Control unit - 17-way connector
XC6 Control unit - 13-way connector
XD Engine stop diode - 2-way connector
XD1 Parking brake diode - 2-way connector
XST2 Side instrument cluster - 36-way connector
Y12 Proportional solenoid valves
NAME DESCRIPTION
