70 SECTION 55 - ELECTRICAL SYSTEM
COMPONENTS AND CONNECTORS
NAME DESCRIPTION
A1 Right speaker (optional)
A2 Left speaker (optional)
A23 EGS
A53 Radio (optional)
A106 Engine control unit
A107 Water in fuel sensor
B4 Air filter switch
B5 Fuel level sender
B24 Accelerator knob
B25 Foot accelerator
B26 Loader bucket sensor
B30 Parking brake
B66 Transmission oil temperature switch
B69 A/C pressure switch
B74 Trasmission oil pressure switch
B129 Brake oil level sensor
E15 Rotating beacon
E16 Rotating beacon
E17 Socket light
E18 Cab light
E27 Number plate light
E28 Rear left light
E29 Rear right light
E38 Rear right work light
E40 Rear right work light (optional)
E44 Front right work light
E45 Front right work light (optional)
E46 Rear left work light (optional)
E47 Rear left work light
E50 Front left work light (optional)
E51 Front left work light
E121 Front left light/horn
E133 Front right light
F1 General fuse
F2 Power supply fuse
F4 Third speed blower fuse
F5 Water in fuel fuse
F31
Fuse for anti-theft device, diagnostic
socket, menu scroll switch, display enter
switch, side instrument cluster
FG4 Fuse A/C
G1 Battery
G67 Alternator
H7 Reverse buzzer
H32 Audible alarm
HA2 Horn
K14 Transmission relay
K102 Relay for start signal from the control unit
K103 Start relay
K104 Engine start relay
K105 A/C relay
M1 Starter motor
M39 Rear windshield wiper
M41 Blower motor (optional)
M49 Front windshield wiper
M56 Front windshield washer
M57 Rear windshield washer
M64 A/C compressor
S2 4WD switch
S3 Hand hammer switch
S4 Hydraulic speed control switch
S5 Drive switch
S15 Start switch
S23 Differential lock switch
S28 Transmission disconnect button
S29 Front claxon switch
S34 Left door switch
S35 Right door switch
S36 Rear hammer button
S42 Warning switch
S126 Lights switch
S130 Windshield wiper/washer switch
S135 Backhoe attachment travel lock switch
S136 Menu scroll switch
S137 Rear work light switch
S138 Rear pump switch
S139 Display enter switch
S140 Backhoe attachment travel lock switch
S141 Front work light switches
S160 Rear horn switches
