SECTION 55 - ELECTRICAL SYSTEM 71
SB1 Battery master switch
ST1 Side instrument cluster
ST3 4x1 bucket control lever
X1
General engine line interface - 18-way
connector
X10 General line interface - 31-way connector
X12
General cab line interface - 5-way
connector
X13 General line - 17-way connector
X14 Anti-theft device - 11-way connector
X15.1 Start connector
X15.2 Start connector
X17 Seat (optional) - 4-way connector
X21 Diagnostics - 10-way connector
X22 5-way connector
X23 2-way connector
X24 Accelerator knob - 6-way connector
X25 Accelerator pedal - 6-way connector
X26
Loader attachment sensor - 3-way
connector
X27 Number plate light - 2-way connector
X28 Rear left light - 4-way connector
X29 Rear right light - 4-way connector
X30
Speed control solenoid valve - 2-way
connector
X32 Horn - 2-way connector
X34 Drive control - 2-way connector
X35 Hand hammer button - 2-way connector
X36 Rear hammer button - 2-way connector
X37 Rear right light - 4-way connector
X38 Rear right light - 4-way connector
X39
Rear windshield wiper motor - 4-way
connector
X40 Rear right light - 4-way connector
X41 Blower motor - 2-way connector
X42 Right direction indicator - 4-way connector
X43 Beacon lamp - 4-way connector
X44 Front left light - 4-way connector
X45 Air conditioning - 11-way connector
X46 Rear left light - 4-way connector
X47 Rear left light - 4-way connector
X48 4-way connector
NAME DESCRIPTION
X49 6-way connector
X50 Front right lights - 4-way connector
X51 Front left ìlights - 4-way connector
X52
Front left direction indicator - 4-way
connector
X53 8-way connector
X54 Radio - 8-way connector
X55 2-way connector
X56 Windshield wiper pump - 2-way connector
X57 Windshield wiper pump - 2-way connector
X58
Front right light (optional) - 5-way
connector
X64 Air conditioning switch - 1-way connector
X67 Alternator - 3-way connector
X69
Air conditioning pressure switch - 2-way
connector
X72 3-way connector
X80 2-way connector
X81 2-way connector
X82 10-way connector
X83 2-way connector
X87
Left general line interface - 13-way
connector
X88
Right side general line interface - 17-way
connector
X106 Engine control unit - 89-way connector
X107 Water in fuel - 3-way connector
X110 Air conditioning - 3-way connector
X111 Air conditioning - 9-way connector
X124 Quick coupler
X128 Optional
X130 12-way connector
X132 6-way connector
X144 2-way connector
X201.P Pilot control - 1-way connector
X201.S Pilot control - 1-way connector
X202
Backhoe attachment travel lock solenoid
valve - 2-way connector
X203
Backhoe attachment travel lock solenoid
valve - 2-way connector
X204 Horn switch - 2-way connector
X206 Bucket level - 2-way connector
NAME DESCRIPTION
