72 SECTION 55 - ELECTRICAL SYSTEM
X207
Speed control solenoid valve (optional) - 2-
way connector
X208 Loader bucket - 2-way connector
X209
Rear hammer solenoid valve - 2-way
connector
X210
Transmissione disconnect - 2-way
connector
XC1
Fuse and relay control unit line interface -
general line - 11-way connector
XC2
Fuse and relay control unit line interface -
general line - 7-way connector
XC3
Fuse and relay control unit line interface -
general line - 21-way connector
XC4
Fuse and relay control unit line interface -
general line - 21-way connector
XC5
Fuse and relay control unit line interface -
general line - 17-way connector
XC6
Fuse and relay control unit line interface -
general line - 13-way connector
XST1 Side instrument cluster - 20-way connector
XST2
Front instrument cluster - 20-way
connector
XX Pilot control cable
Y8 Differential solenoid valve
Y12 4x1 bucket solenoid valve (optional)
Y24
Backhoe attachment travel lock solenoid
valve
Y25
Backhoe attachment travel lock solenoid
valve
Y26
Backhoe attachment travel lock solenoid
valve
Y27
Backhoe attachment travel lock solenoid
valve
Y30 Speed control solenoid valve (optional)
Y32 Rear hammer solenoid valve (optional)
Y34 Drive control solenoid valve (optional)
Y35 Hand hammer solenoid valve
NAME DESCRIPTION
