86 SECTION 55 - ELECTRICAL SYSTEM
S140 Backhoe attachment travel lock switch
S141 Front work light switches
S144 Beacon lamp switch
S160 Rear horn switches
S205 Transmission disconnect switch
SB1 Battery master switch
ST1 Side instrument cluster
ST3 4x1 bucket control lever
X1
General engine line interface - 18-way
connector
X2
Preheating relay (optional) - 2-way
connector
X4 Air filter sensor - 2-way connector
X5 Fuel level sensor - 2-way connector
X6
Forward gear solenoid valve - 2-way
connector
X7 Reverse travel buzzer - 2-way connector
X8 Solenoid valve - 2-way connector
X10 General line interface - 31-way connector
X12
General cab line interface - 5-way
connector
X13 General line - 17-way connector
X14 Anti-theft device - 11-way connector
X15.1 Start connector
X15.2 Start connector
X17 Seat (optional) - 4-way connector
X21 Diagnostics - 10-way connector
X21 7-way connector
X22 Quick coupler
X23 2-way connector
X24 Knob - 6-way connector
X25 Accelerator pedal - 6-way connector
X26
Backhoe attachment sensor - 3-way
connector
X27 Number plate light - 2-way connector
X28 Rear left light - 4-way connector
X29 Rear right light - 4-way connector
X30
Speed control solenoid valve - 2-way
connector
X32 Horn - 2-way connector
X34 Drive control - 2-way connector
X35 Hand hammer button - 2-way connector
NAME DESCRIPTION
X36 Rear hammer button - 2-way connector
X37 Rear right light - 4-way connector
X38 Rear right light - 4-way connector
X39
Rear windshield wiper motor - 4-way
connector
X40 Rear right light - 4-way connector
X41 Blower motor - 2-way connector
X42 Right direction indicator - 4-way connector
X43 Beacon lamp - 4-way connector
X44 Front left light - 4-way connector
X45 Air conditioning - 11-way connector
X46 Rear left light - 4-way connector
X47 Rear left light - 4-way connector
X48 4-way connector
X49 6-way connector
X50 Front right lights - 4-way connector
X51 Front left ìlights - 4-way connector
X52
Front left direction indicator - 4-way
connector
X52 2-way connector
X53 8-way connector
X54 Radio - 8-way connector
X55 Seat safety switch - 2-way connector
X55 2-way connector
X56 Windshield wiper pump - 2-way connector
X57 Windshield wiper pump - 2-way connector
X58 Left direction indicator - 4-way connector
X64 Air conditioning switch - 1-way connector
X67 Alternator - 3-way connector
X69
Air conditioning pressure switch - 2-way
connector
X72 3-way connector
X80 2-way connector
X81 2-way connector
X82 10-way connector
X83 2-way connector
X87
Left general line interface - 13-way
connector
X88
Right side general line interface - 17-way
connector
X106 Engine control unit - 89-way connector
X107 Water in fuel - 3-way connector
NAME DESCRIPTION
