SECTION 55 - ELECTRICAL SYSTEM 87
X110 Air conditioning - 3-way connector
X111 Air conditioning - 9-way connector
X124 Quick coupler
X128 Optional
X130 12-way connector
X132 6-way connector
X144 2-way connector
X202
Backhoe attachment travel lock solenoid
valve - 2-way connector
X203
Backhoe attachment travel lock solenoid
valve - 2-way connector
X204 Horn switch - 2-way connector
X208 Loader attachment - 2-way connector
XC1
Fuse and relay control unit line interface -
general line - 11-way connector
XC2
Fuse and relay control unit line interface -
general line - 7-way connector
XC3
Fuse and relay control unit line interface -
general line - 21-way connector
XC4
Fuse and relay control unit line interface -
general line - 21-way connector
XC5
Fuse and relay control unit line interface -
general line - 17-way connector
XC6
Fuse and relay control unit line interface -
general line - 13-way connector
XST1 Side instrument cluster - 20-way connector
XST2 Front instrument cluster - 20-way connector
XX From pilot control cable
Y12 Optional 4x1 bucket solenoid valve
Y24
Backhoe attachment travel lock solenoid
valve
Y25
Backhoe attachment travel lock solenoid
valve
Y26
Backhoe attachment travel lock solenoid
valve
Y27
Backhoe attachment travel lock solenoid
valve
Y30 Speed control solenoid valve (optional)
Y32 Rear hammer solenoid valve (optional)
Y34 Drive control solenoid valve (optional)
Y35 Hand hammer solenoid valve
Y91 Steering solenoid valve
Y92 4WS steering solenoid valve
Y93 Crab steering solenoid valve
NAME DESCRIPTION
Y94 2WS steering solenoid valve
Y206 Bucket level solenoid valve
NAME DESCRIPTION
