SECTION 55 - ELECTRICAL SYSTEM 117
4.4 ON BOARD ERROR CODE RETRIEVAL
↵
Z
Stored error code
Z
Page 1/6
3-second scroll unless
the up/down button is
pressed
CODE 3059
↵
OCCURRENCE 3
TIME 1004.5
Page 2/6
CODE 3009
OCCURRENCE 2
TIME 1010.6
Page 3/6
Occurrence counter will be incremented on transition from
inactive to active status. Status has to be stored in EEPROM and
checked at key on. Only the hour count of the last occurrence will
be stored per SAE convention.
CODE 1018
OCCURRENCE 1
TIME 1024.5
Page 4/6
CODE 3022
OCCURRENCE 1
HOUR 969 .4
Page 5/6
CODE 3113
OCCURRENCE 2
TIME 1050.6
Page 6/6
CODE 1003
OCCURRENCE 3
TIME 1076.4
MAIN SCREEN
To Next Page
