4.10 WARNING MESSAGES
Function Lamp Alarm Lamp Display
lamp
Condition DTC SA Description Priority Color
Engine
coolant too
high
Continuous
Coolant
above 112 °C
for 5 seconds
1002 VCM
Coolant
temperature
signal - Above
normal
1Red
Engine oil
pressure
too low
Continuous
Pressure
< 26 bar
500> rpm
3028 ECU
Oil pressure
sensor -
pressure too
low
1Red
Transmissi
on oil
pressure
too low
Continuous
Switch
closed to
ground for 25
seconds
1008 VCM
The engine
must be
running with
switch closed
for 25 seconds
1Red
Malfunction Continuous
5 seconds
without
message
1051 ECU
Timeout of
message
1Red
Malfunction Continuous
25 seconds
without
message
1053 ECU
Timeout of
message
1Red
Malfunction Continuous
5 seconds
without
message
1054 VCM
Timeout of
message
engine
temperature
1Red
Malfunction Continuous
5 seconds
without
message
1055 VCM
Timeout of
message inlet/
exhaust
1Red
Malfunction Continuous
5 seconds
without
message
1056 VCM
Timeout of
message
engine fluid
1Red
Malfunction Continuous
5 seconds
without
message
1057 VCM
Timeout of
message
vehicle
electrical
1Red
Malfunction Continuous
5 seconds
without
message
1059 VCM
Timeout of
message
display
1Red
Transmissi
on oil
temperatur
e too high
Continuous
Transmission
oil above
11
5 °C for 5
seconds
1009 VCM
Transmission
oil temperature
limit reached
1Red
STOP
STOP
STOP
STOP
STOP
STOP
STOP
STOP
STOP
STOP
STOP
