Case 580SR+ - Page 960

132 SECTION 55 - ELECTRICAL SYSTEM
Air
conditionin
g not
functional
One second
alarm every
30 seconds
Switch
closed to
Vbat for 5
seconds
1003 VCM
Air
conditioning
system
pressure
4 Amber
Hydraulic
filter
restriction
One second
alarm every
30 seconds
Switch
closed to
ground for 5
seconds
1004 VCM
Hydraulic filter
threshold
4Red
Fuel
contaminat
ed with
water
One second
alarm every
30 seconds
Display
message
1022 VCM 4 Amber
Fuel level
sensor
One second
alarm every
30 seconds
Fuel sender
above 9 V for
5 seconds
1043 VCM
Fuel sender
shorted high -
park gauge
4 Amber
Fuel level
sensor
One second
alarm every
30 seconds
Fuel sender
below 0.5 V
for 5 seconds
1044 VCM
Fuel sender
shorted low -
park gauge
4 Amber
Fuel level
sensor
One second
alarm every
30 seconds
Input is
switched
battery for 5
seconds
1045 VCM
Fuel sender
open circuit -
park gauge
4 Amber
Transmissi
on
temperatur
e sensor
One second
alarm every
30 seconds
Transmission
temperature
sender above
9 V for 5
seconds
1046 VCM
Transmission
temperature
sender shorted
high
4 Amber
Transmissi
on
temperatur
e sensor
One second
alarm every
30 seconds
Transmission
temperature
sender below
0.5 V for 5
seconds
1047 VCM
Transmission
temperature
sender shorted
lo
w
4 Amber
Transmissi
on
temperatur
e sensor
One second
alarm every
30 seconds
Input is
switched
battery for 5
seconds
1048 VCM
Transmission
temperature
open circuit
4 Amber
Function Lamp Alarm Lamp Display
lamp
Condition DTC SA Description Priority Color
