Case 580SR+ - Page 959

SECTION 55 - ELECTRICAL SYSTEM 131
Seat not in
driving
position
Continuous
Switch
closed to
ground with
vehicle in
gear and no
park brake
N/A VCM
This must
have a
debounce time
of less then
500 ms
2Amber
Boost air
temperatur
e too high
One second
alarm every
30 seconds
Boost
temperature
over
88 °C for 5
seconds
1018 VCM
Engine over
operating
boost air
temperature
3Amber
Engine
coolant too
high
One second
alarm every
30 seconds
Coolant
above 106 °C
for 5 seconds
1019 VCM
Engine over
operating
coolant
temperature
Amber
Engine
coolant too
high
One second
alarm every
30 seconds
3007 ECU
Coolant
temperature
signal source
high
3Amber
Transmissi
on oil
above
105 °C
One second
alarm every
30 seconds
Coolant
above 105 °C
for 5 seconds
1020 VCM
Transmission
over operating
temperature
3Amber
Fuel
temperatur
e too high
One second
alarm every
30 seconds
Fuel over
82 °C for 5
seconds
1021 VCM
Fuel over
operating
temperature
3Amber
Fuel
temperatur
e too high
One second
alarm every
30 seconds
3015 ECU
Fuel
temperature
signal source
high
3Amber
Fuel
temperatur
e too high
One second
alarm every
30 seconds
3016 ECU
Fuel
temperature
signal no
signal
3Amber
Air filter
restriction
One
second
alarm every
30 seconds
Switch
closed to
ground for 5
seconds
1001 VCM
Air filter
threshold
4Red
Function Lamp Alarm Lamp Display
lamp
Condition DTC SA Description Priority Color
