130 SECTION 55 - ELECTRICAL SYSTEM
Hand
accelerator
signal out
of range
One second
alarm every
30 seconds
Accelerator
above 4.75 V
for 5 seconds
1035 VCM
Hand
accelerator
sensor -signal
above range
2 Amber
Hand
accelerator
signal out
of range
One second
alarm every
30 seconds
Accelerator
under 0.25 V
for 5 seconds
1036 VCM
Hand
accelerator
sensor -signal
above range
2 Amber
Hand
accelerator
signal out
of range
One second
alarm every
30 seconds
1037 VCM
Hand
accelerator
sensor - no
signal
2 Amber
Hand
accelerator
signal out
of range
One second
alarm every
30 seconds
Accelerator
above 9 V for
5 seconds
1038 VCM
Hand
accelerator
sensor -
shorted high to
Vbat
2 Amber
Hand
accelerator
signal out
of range
One second
alarm every
30 seconds
Accelerator
under 0.5 V
for 5 seconds
1039 VCM
Hand
accelerator
sensor -
shorted low to
ground
2 Amber
Hand
accelerator
5 V supply
One second
alarm every
30 seconds
Accelerator
above 5.1 V
for 5 seconds
1031 VCM
Hand
accelerator
supply voltage
too high
2 Amber
Hand
accelerator
5 V supply
One second
alarm every
30 seconds
Accelerator
under 4.9 V
for 5 seconds
1032 VCM
Hand
accelerator
supply voltage
too low
2 Amber
Hand
accelerator
5 V supply
One second
a
larm every
30 seconds
Accelerator
above 9 V for
5 seconds
1033 VCM
Hand
accelerator
supply shorted
high
2 Amber
Hand
accelerator
5 V supply
One second
alarm every
30 seconds
Accelerator
under 0.5 V
for 5 seconds
1034 VCM
Hand
accelerator
supply shorted
low
2 Amber
Function Lamp Alarm Lamp Display
lamp
Condition DTC SA Description Priority Color
