SECTION 55 - ELECTRICAL SYSTEM 147
6.4 REMOVAL
Electrical disconnections of the alternator
1. Disconnect the negative cable from the battery.
2. Disconnect the battery cable (1) from terminal
B+ (2).
3. Disconnect the connector (3).
Removing the alternator
1. Free the tension roller (1) using a suitable
wrench, then remove the belt (2).
2. Remove the screw (3) and the nut (4).
3. Remove the bolt (5).
4. Remove the alternator.
