Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 3- DEVICE INFORMATION Page 3.2
3.2. DEVICE INFO >WAN INFORMATION
This section provides an overview of the Wide Area Network information
Interface
Description
Type
VlanMuxId
Igmp
NAT
Firewall
Status
IPv4 Address
pppoa
Pppoa_0_0_38
pppoA
Disabled
Disabled
Enabled
Enabled
Connected
81.136.19.67
Interface pppoa This is the WAN interface being used
Description Description given to the WAN Interface
Type Reflects if this is IPoA, PPPoE, PPPoA etc.
VLAN Mux ID Shows if enabled or disabled
IGMP Shows if enabled or disabled
NAT Shows if enabled or disabled (NB.for some protocols it cant be disabled)
Firewall Shows if enabled or disabled. (NB. for some protocols this cant be disabled)
Status Connected, shows that the link is up
IPv4 Address This is the WAN IP Address provided to you by your ISP
3.3. DEVICE INFO >STATISTICS
3.3.1. DEVICE INFO >STATISTICS > LAN
This option displays the Ethernet Interface statistics on the 6401 Rugged Router
Interface
Received
Transmitted
Bytes
Pkts
Errs
Drops
Bytes
Pkts
Errs
Drops
eth1
358893
2835
0
0
407710
1096
0
0
eth2
0
0
0
0
0
0
0
0
eth3
548407
4683
0
0
940061
2069
0
0
eth4
0
0
0
0
0
0
0
0
3.3.2. DEVICE INFO >STATISTICS > WAN
This option displays the Wide Area Network Interface statistics on the 6401 Rugged Router
Interface
Description
Received
Transmitted
Bytes
Pkts
Errs
Drops
Bytes
Pkts
Errs
Drops
pppoa
Pppoa_0_0_38
309560
2158
0
0
665133
1862
0
0
Reset Statistics
Select the ‘reset statistics’ to set the statistics back to zero
