Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.45
5.9. ROUTING
5.9.1 DEFAULT GATEWAY
ADVANCED SETUP > ROUTING
On entering the Routing menu the first option is to select the Default Gateway,
out of the router.
The default gateway interface list can have multiple WAN interfaces served as
system default gateways but only one will be used according to the priority with
the first being the highest and the last one the lowest priority if the WAN interface
is connected. Priority order can be changed by removing all and adding them back
in again.
The router will automatically enter any configured WAN interfaces into the
‘Default Gateway’.
5.9.2 STATIC ROUTES.
This menu allows the network manager to configure static routes on the 6401 router. Up to 32 Static
routes can be configured in the 6401. On entering the menu option a table is displayed showing what
static routes have been configured as shown below.
IP Version
DstIP/ PrefixLength
Gateway
Interface
Metric
Remove
IPv4
172.16.10.20/16
pppoa0
2
Routing -- Static Route Add
Enter the destination network address, subnet mask, gateway AND/OR available WAN interface then
click "Apply/Save" to add the entry to the routing table.
Static Routing Menu options
IP Version
Select IPv4 or IPv6
Destination IP address/prefix length:
Enter the destination IP address with an address subnet mask
using the CIDR format. For example 172.16.10.20/16 or
192.168.1.1/24
Gateway (Only if using Ethernet port
as a WAN port)
Enter the Gateway address out of the local LAN
Interface
pppoa0
Metric
Select the maximum number of hops to the destination
WAN Service
VPN
LAN
NAT
Security
Parental Control
Quality of Service
Routing
Layer 2 Interface
Advanced Setp
