Case 6401 - CONFIGURING PPP over Ethernet

Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.13
5.2.2.3 CONFIGURING PPP Over Ethernet (PPPoE - layer 2 EOA)
Wide Area Network (WAN) Service Setup
Choose Add, Remove or Edit to configure a WAN service over a selected interface.
Interface
Description
Type
Vlan8021p
VlanMuxId
Igmp
NAT
Firewall
Remove
Edit
Select Add to start configuring a PPPoE Service, and then select the interface from the following
drop down menu;
WAN Service Configuration
Select WAN Service type:
X
PPP over Ethernet (PPPoE) (Select this as we are configuring PPPoE)
IP over Ethernet
Bridging
Enter Service Description
Example – PPPoE_0_0_45
Select next to configure your ISP settings
6401 Rugged Router
WAN Service
VPN
LAN
NAT
Security
Parental Control
Quality of Service
Routing
DNS
DSL
UPnp
DNS Proxy
Print Server
Layer 2 Interface
Advanced Setp
Interface Grouping
IP Sec
Certificate
Multicast
Diagnostics
Management
ATM Interface
Eth Interface
WAN Service Interface Configuration
Select a layer 2 interface for this service
Note: For ATM interface, the descriptor string is (portId_vpi_vci)
For PTM interface, the descriptor string is (portId_high_low)
Where portId=0 --> DSL Latency PATH0
portId=1 --> DSL Latency PATH1
portId=4 --> DSL Latency PATH0&1
low =0 --> Low PTM Priority not set
low =1 --> Low PTM Priority set
high =0 --> High PTM Priority not set
high =1 --> High PTM Priority set
Atm1/(0_0_45) q
