3.3.4. DEVICE INFO >STATISTICS > xDSL
Statistics xDSL
Mode
ADSL2+
Displays the DSL mode
Traffic Type
ATM
Displays traffic type
Status
UP
Displays status of the link ( Disabled – Establishing- Linkup)
Link Power State
L0
See Note below
Downstream
Upstream
Downstream
Upstream
Line Coding(Trellis):
On
Off
0
0
SNR Margin (0.1 dB):
117
243
0
0
Attenuation (0.1 dB):
265
130
0
0
Output Power (0.1 dBm):
208
120
0
0
Attainable Rate (Kbps): (Max you can obtain)
13024
1472
0
0
Path 0
Path 1
Downstream
Upstream
Downstream
Upstream
Rate (Kbps): (Current Sync rate)
6653
448
MSGc (#of bytes in overhead channel
message
57
74
B# (of bytes in mux data frame)
36
14
M#(of Mux Data Frames in FEC Data Frame)
4
4
T (Mux data frames over sync bytes)
4
1
R# ( of check bytes in FEC data frame)
16
14
S (Ratio of FEC over PMD Data Frame
Length)
0.1767
4.0
L (# of bits in PMD Data Frame):
2399
148
D (Interleaver depth)
160
2
Delay (msec)
7.6
2.0
INP (DMT symbol)
4.26
0.75
Super Frames:
95843
53200
Super Frame Errors:
0
5
RS Words:
24152096
1067199
RS Correctable Errors:
20
7
RS Uncorrectable Errors:
0
0
HEC Errors:
0
4
OCD Errors:
0
0
LCD Errors:
0
0
Total Cells:
1674315
1121057
Data Cells:
2123
4223
Bit Errors:
0
215
Total ES:
0
5
Total SES:
0
0
Total UAS:
23
23
Status
This indicates the status of the connection. The link can be up but your not connected to a service, in
which case the Link Light on the front will be ‘off’, but the link will show up in the statistics.
The status goes through – Three stages – disabled – Establishing – Link up.
Link Power Status- The ADSL (G.992.3) and ADSL2+ (G.992.5) recommendations define a power
management feature. Its primary application is to reduce the power consumption and the thermal
dissipation of ADSL chip sets.
