5.3.2 L2TP CONFIGURATION
ADVANCED SETUP > VPN>L2TP
This menu option allows you to configure an L2TP (Level 2 Tunnelling protocol) service.
On selecting the option the following page appears
L2TP Client Side PPP Connection
Choose Add, Remove to configure a PPP over L2TP WAN Service)
Tunnel name
LNS IP Address
Remove
Select ‘Add’ to add a new tunnel, this produces the following menu options.
Add a L2TP Client Side PPP Connection (PPPoL2TP WAN Service)
Menu Option
Example
Meaning
Tunnel name
Tunnel
Enter a freeform name
L2TP Server IP Address
80.80.16.240
Enter the IP Address of the remote server
PPP Username and Password
PPP usually requires that you have a user name and password to establish your connection. In the
boxes below, enter the user name and password that your ISP has provided to you
Menu Option
Example
Meaning
PPP Username
Case
Enter the name provided by your ISP
PPP Password
6401ADSL
Enter the password provided by your ISP
Authentication Method
Auto
Select from drop down menu
(Auto, PAP, CHAP, MSCHAP)
Enable Full Cone Nat
(Default not selected)
Dial on demand with idle timer
(Default Not selected)
Use Static IPv4 Address (If selected field below opens)
(Default Not selected)
IPv4 Address
Enter your static IPv4 Address
Enable PPP Debug Mode
(Default Not selected)
Multicast Proxy
Enable Multicast IGMP Proxy
(Default Not selected)
Select Next to see the WAN Set up Summary
Make sure that the settings below match the settings provided by your ISP.
