Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.43
5.8.8. CONFIGURATION EXAMPLES
EXAMPLE 1 – LAN – TELNET TRAFFIC ENTERING FROM LAN
Only option for this configuration
Specify Classification Criteria
A blank criterion indicates it is not used for classification.
LAN, WAN, Local, eth1, eth2, eth3,eth4
Select from drop down list
IP, ARP, IPv6, PPPoE_Disc, PPPoE_SES, 8865,
8866, 802.1Q
Enter Source Device MAC Address
Enter Source Device MAC Mask
Enter Destination MAC Address
Enter destination MAC Mask
Left blank to allow access to any remote IP address
Select port number for the application
Select port number for the application
Specify Classification Results
Must select a classification queue.
A blank mark or tag value means no change
Assign Classification Queue:
Select from a drop down menu, these are
previously configured Queues
Mark Differentiated Service
Code Point (DSCP):
Provides QoS at the MAC Layer. Select from drop
down menu range 0 (Lowest) to 7 (Highest)
Enter VLAN Tag ID if tagged VLANS are in use
Enter a data rate in Kbps
Having selected this click save and the following table will be displayed showing the configuration
