Case 6401 - CONFIGURING Ipoe

Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.16
5.2.2.4 CONFIGURING IPoE (IP Over Ethernet – layer 2 EOA )
Wide Area Network (WAN) Service Setup
Choose Add, Remove or Edit to configure a WAN service over a selected interface.
Interface
Description
Type
Vlan8021p
VlanMuxId
Igmp
NAT
Firewall
Remove
Edit
Select Add to start configuring an IPoE Service, and then select the interface from the following drop
down menu;
WAN IP Settings
Enter information provided to you by your ISP to configure the WAN IP settings.
Notice: If "Obtain an IP address automatically" is chosen, DHCP will be enabled for PVC in IPoE
mode. If "Use the following Static IP address" is chosen, enter the WAN IP address, subnet mask and
interface gateway
X
Obtain and IP Address Automatically (Default)
Option 60 Vendor ID
Option 61 IAID
8 hexadecimal digits
Option 61 DUID
hexadecimal digits
Option 125
X
Disable
Enable
Use the following Static IP Address (Select if using a static IP Address)
WAN IP Address
WAN Subnet Mask
WAN Gateway IP Address
6401 Rugged Router
WAN Service
VPN
LAN
NAT
Security
Parental Control
Quality of Service
Routing
DNS
DSL
UPnp
DNS Proxy
Print Server
Layer 2 Interface
Advanced Setp
Interface Grouping
IP Sec
Certificate
Multicast
Diagnostics
Management
ATM Interface
Eth Interface
WAN Service Interface Configuration
Select a layer 2 interface for this service
Note: For ATM interface, the descriptor string is (portId_vpi_vci)
For PTM interface, the descriptor string is (portId_high_low)
Where portId=0 --> DSL Latency PATH0
portId=1 --> DSL Latency PATH1
portId=4 --> DSL Latency PATH0&1
low =0 --> Low PTM Priority not set
low =1 --> Low PTM Priority set
high =0 --> High PTM Priority not set
high =1 --> High PTM Priority set
Atm1/(0_0_45) q
